Motor
Rear-Drive Motor
500W
Samsung Battery
48V*20Ah
per Charge (PAS1)
135KM
UL Certification
2271 & 2849
Payload Capacity
135+35 KG
Top Speed Of Trike
25 KPH (Locked)
Arisetan II M-360 Semi-Recumbent eTrike
ARISETAN II M-360 fat tyre electric trike is the world's first semi-recumbent electric trike for the disabled and those with back pain.
Individuals facing disability or mobility challenges may qualify for financial assistance to acquire this sensational Electric Tricycle.
Discover Arisetan Ⅱ
Semi-Recumbent Design
Experience the joy of riding in comfort and style with this exceptional semi-recumbent electric trike.
UL-Certified Samsung Cell Battery
The 48V*20Ah high-capacity battery provides plenty of power with a range of up to 135 KM. The UL-certifiedbattery in the US and Canada keeps your ride safe and secure.
500W Rear Motor
The rear-mounted motor makes the Arisetan M-360 much more stable and helps maintain a better balanced ride when climbing hills.
Specification
Electronics
Bafang 48V*500W Rear Brushless Hub Motor, 70Nm motor torque
Battery
Samsung 48V*20Ah Cells Battery, Charging Time 10 Hours And Rated For 1,000 Charge Cycles
Display
Addmotor 5 Inch LCD Display
Controller
Addmotor 25A Controller
Throttle
Variable Speed Control - Removable Thumb Throttle
HeadLight
Powered By Main Battery And Controlled By Display
Taillight
Powered By Main Battery And Controlled By Display, with Turning Signal
Wiring
Water-Resistant Connectors and Wiring Harness
Pedal Assist
Upgraded 7 Level Pedal Assist, Torque Sensor
Charger
48V*2.0A 5 Pins, DC Charger, 5 Pins With Auto Magnetic Suction
Components
Frame
7A19 Aluminum Alloy Frame
Front Fork
Oil Spring Fork with 25mm of Travel
Brake Lever
Tektro EL555-RT/EL550-RS
Rotors
MD300 180mm Front/Shanfeng*2 Pics 180mm Rear
Chain
KMC Rust Resistant Chain
Tyres
Addmotor 51cm X 10cm Fat Tyres
Chain Puller
Shimano 7 Speeds ALTUS M310
Horn
Sensitive Front Horn
Fender
Front and Rear Fenders
Basket
Metal Large Capacity Rear Basket with Waterproof Bag
